Rigid Mounted Breakaway Coupling - Female - Body Size 1/2" Models 265, 275, 290, 298, 350, 352, 362, 365, 372, 375, 382, 390, 390T, 398, 399, 670, 675, 690, 698, 698T, 699
Part No.
Product Details
57026
Product Details
Rigid Mounted Breakaway Coupling - Female - Body Size 1/2" - Male Thread Size M22 x 1.5
This series of ISO A female couplings are designed primarily for the agricultural industry and incorporate a push/pull design. The coupling is panel mounted using circlip grooves on the locking sleeve.
Body Size: 1/2”
Thread: M22 x 1.5
Thread Length: 12.0mm
D1: 38.0mm / 1.5"
L1: 111.0mm / 4.37"
A/F: 32.0mm / 1.26"
APPLICATIONS
• Agricultural
• Construction
• Mobile
• General hydraulics
FEATURES
• Can be connected with standard ISO A 1/2” male couplings
• Can be connected with residual pressure in the line (male side only)
• Release mechanism protects coupling and hose from damage in event of accidental separating force
• Locking ball system allows quick connection
• Bidirectional flow
SPECIFICATIONS
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Carbon steel with trivalent plating
• Fitted with NBR seals
• Conforms to ISO 7241 : 2014 A
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure (Coupled) - 300 bar (Flow in Litres Per Minute) - 4350 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 1000 bar (Flow in Litres Per Minute) - 14500 PSI (Flow in Gallons Per Minute)
• Rated Flow - 45 bar (Flow in Litres Per Minute) – 12 PSI (Flow in Gallons Per Minute)
Suitable for Massey Ferguson.
