£4.10 Inc VAT
£3.42
Exc VAT
Related Items(1)
Quick Release Coupling - Male - Body Size 1/2" Models 2000, 2600, 2610, 2810, 2910, 3000, 3600, 3610, 3910, 4000, 4100, 4110, 4600, 4610, 5000, 5600, 5610, 6410, 6600, 6610, 6700, 6710, 6810, 7000, 7700, 7710, 7810, 8210
Part No.
Product Details
50234
Product Details
Quick Release Coupling - Male - Body Size 1/2" - Thread Size 3/4"-16 UNF
This series of ISO A couplings are the ideal choice where a tough, durable product of superior quality is required. They are perfectly suited to agricultural and industrial applications.
Body Size: 1/2”
Thread: 3/4"-16 UNF
D2: 20.5mm / 0.81"
L2: 43.5mm / 1.71"
A/F: 27mm / 1.06"
APPLICATIONS
• Agricultural
• Construction
• Mobile
• General hydraulics
FEATURES
• Poppet valves have balanced springs
• Locking ball system allows quick connection
• Bidirectional flow
SPECIFICATIONS
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Carbon steel with trivalent plating
• Fitted with NBR seals
• Conforms to ISO 7241 : 2014 A
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure (Coupled) - 320 bar (Flow in Litres Per Minute) - 4640 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 1500 bar (Flow in Litres Per Minute) - 21750 PSI (Flow in Gallons Per Minute)
• Rated Flow - 45 bar (Flow in Litres Per Minute) – 12 PSI (Flow in Gallons Per Minute)
