£17.99 Inc VAT
£14.99
Exc VAT
Quick Release Coupling - Female - Body Size 1/2" Models 1020, 1030, 1040, 1120, 1130, 1140, 1630, 1640, 1830, 1840, 2020, 2030, 2040, 2120, 2130, 2140, 3030, 3040, 3120, 3130, 3140, 675, 690, 698, 698T, 699, 840, 940
Part No.
Product Details
50235
Product Details
Quick Release Coupling - Female - Body Size 1/2" - Thread Size 3/4" - 16 UNF
This series of ISO A female couplings are designed primarily for the agricultural industry and incorporate a push/pull design. The coupling is panel mounted using circlip grooves on the locking sleeve.
Body Size: 1/2”
Thread: 3/4" - 16 UNF
D1: 38.1mm / 1.5"
L1: 66mm / 2.6"
A/F: 27mm / 1.06"
APPLICATIONS
• Agricultural
• Construction
• Mobile
• General hydraulics
FEATURES
• Can be connected with standard ISO A 1/2” male couplings
• Release mechanism protects coupling and hose from damage in event of accidental separating force
• Locking ball system allows quick connection
• Bidirectional flow
SPECIFICATIONS
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Carbon steel with trivalent plating
• Fitted with NBR seals
• Conforms to ISO 7241 : 2014 A
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure (Coupled) - 320 bar (Flow in Litres Per Minute) - 4640 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 1500 bar (Flow in Litres Per Minute) - 21750 PSI (Flow in Gallons Per Minute)
• Rated Flow - 45 bar (Flow in Litres Per Minute) – 12 PSI (Flow in Gallons Per Minute)
