Studs Cylinder Head

Cylinder Head Stud Kit Cylinder Head Stud Kit Dimensions - 2 Long (150mm Overall) - 12 Medium (131mm Overall) - 8 Short (115mm) - Thread: 1/2UNF - Includes Spring Washers For use with Original engines after serial number 236UA43210 Also To Be Used With 7368 & 7376 Aftermarket Bl... Show More

£73.20 Inc VAT £61.00 Exc VAT

In stock

Qty

Part No.

8449

Cylinder Head Stud - 112MM 1/2" UNC 112MM Grade 4F. Manufacturers recommended Torque procedure: 1. Tighten to 100Nm. 2. Tighten to 150Nm. 3. Wait 5 minutes, then re-check at 150Nm 4.Then Rotate bolt a further 60 Degrees

£11.46 Inc VAT £9.55 Exc VAT

Out of stock

Qty

Part No.

1464A

Stud 97mm For A4.212 Engines up to Engine Number UA78663

£4.42 Inc VAT £3.68 Exc VAT

In stock

Qty

Part No.

92090

Stud 48mm For A4.212 Engines upto Engine Number UA78663

£3.78 Inc VAT £3.15 Exc VAT

In stock

Qty

Part No.

92091

Stud 70mm For A4.212 Engines upto Engine Number UA78663

£3.78 Inc VAT £3.15 Exc VAT

In stock

Qty

Part No.

92089

Cylinder Head Stud Length: 96.5mm Thread - 7/16 UNF

£3.91 Inc VAT £3.26 Exc VAT

In stock

Qty

Part No.

47802

Cylinder Head Stud - 32181459 Cylinder Head Stud - Short Total Length: 89.5mm Shaft Length: 82mm

£2.52 Inc VAT £2.10 Exc VAT

In stock

Qty

Part No.

47804

Cylinder Head Stud Set * Only For Use With Original Block *.

£84.00 Inc VAT £70.00 Exc VAT

In stock

Qty

Part No.

7266

Cylinder Head Stud Kit 85MM TED20 85mm TE Petrol Engine Consists of 10 x Cylinder Head Studs Use with 50143 Nut 7/16" UNF-HT. Exclusive To Agriline.

£75.60 Inc VAT £63.00 Exc VAT

In stock

Qty

Part No.

A-900

Cylinder Head Stud Kit - Ford 4cyl Instructions for Torque settings: Stage 1 - 75 ft lb / 100 Nm. Stage 2 - 80 ft lb / 110 Nm. Stage 3 - 85 ft lb / 115 Nm. Final - 90 ft lb / 122 Nm.

£184.80 Inc VAT £154.00 Exc VAT

In stock

Qty

Part No.

9940

Cylinder Head Stud Kit - Ford 3cyl Instructions for Torque settings; Stage 1 - 75 ft lb / 100 Nm Stage 2 - 80 ft lb / 110 Nm Stage 3 - 85 ft lb / 115 Nm Final - 90 ft lb / 122 Nm Stud Size Is 9/16" Thread Only Suitable For Later Block, Early Blocks Have 1/2" Studs

£186.00 Inc VAT £155.00 Exc VAT

In stock

Qty

Part No.

9939

Cylinder Head Stud 7/16"UNF Perkins Engines A4.212, A4.236, A4.248, T4.236

£3.14 Inc VAT £2.62 Exc VAT

In stock

Qty

Part No.

4797

Cylinder Head Stud 127mm 20C Engine Cylinder Head Stud (14 per Tractor). Exclusive To Agriline. - Overall Length: 127mm - Thread (End 1): 7/16UNF - Thread Length (End 1): 23mm - Thread (End 2): 7/16 UNC - Thread Length (End 2): 18mm

£5.04 Inc VAT £4.20 Exc VAT

In stock

Qty

Part No.

A-857

Cylinder Head Bolt Cylinder Head Bolt. Length:- 205MM Including Bolt Head. Thread:- 1/2" UNC

£7.50 Inc VAT £6.25 Exc VAT

In stock

Qty

Part No.

7499

Cylinder Head Bolt 12cm Cylinder Head Bolt 12cm. Thread: 1/2". All Fordson Majors - 17 Required

£5.36 Inc VAT £4.47 Exc VAT

In stock

Qty

Part No.

7498

Nut Cylinder Stud and Conrod Nut 7/16" UNF-HT Suitable For 8696 Cylinder Head Stud, A-856 Cylinder Head Stud & 7143 Conrod Bolt MF50B Perkins A4.212 Engine - Rocker Arm Screw Nut.

£1.14 Inc VAT £0.95 Exc VAT

In stock

Qty

Part No.

50143

Cylinder Head Stud 32524133 Length: 106.3mm Thread - 7/16 UNF

£6.24 Inc VAT £5.20 Exc VAT

In stock

Qty

Part No.

47801

Cylinder Head Stud Length: 115.1mm Thread - 7/16 UNF

£5.36 Inc VAT £4.47 Exc VAT

In stock

Qty

Part No.

47803

Cylinder Head Stud Length (Inc head): 108.5mm

£2.77 Inc VAT £2.31 Exc VAT

In stock

Qty

Part No.

47806

Cylinder Head Stud Length: 93.3mm Thread - 7/16 UNF

£7.22 Inc VAT £6.02 Exc VAT

In stock

Qty

Part No.

47805

Cylinder Head Stud 110mm 20C Engine Cylinder Head Stud (8 per Tractor). Exclusive To Agriline.

£6.62 Inc VAT £5.52 Exc VAT

In stock

Qty

Part No.

A-858

Cylinder Head Stud Kit 20C TEF Cylinder Head Stud Kit 20C TEF Consists of; 14 x Cylinder Head Stud 127mm 8 x Cylinder Head Stud 110mm Exclusive To Agriline.

£70.80 Inc VAT £59.00 Exc VAT

In stock

Qty

Part No.

A-902

Cylinder Head Bolt 103mm FE35 23C Tractor Cylinder Head Bolt (8 Required per tractor). Exclusive To Agriline.

£7.25 Inc VAT £6.04 Exc VAT

In stock

Qty

Part No.

A-854

Cylinder Head Stud 142mm Length Exclusive to Agriline. Ferguson / Standard Engine Cylinder Head Stud From Serial Number S170174E. 142mm Long. 5 1/2" Long. End A: 7/16" BSW x 3/4" Long. End B: 7/16" UNF x 3/4" Long. Use with 50143 Nut 7/16" UNF-HT 85mm TVO Models

£9.46 Inc VAT £7.88 Exc VAT

In stock

Qty

Part No.

8696

Cylinder Head Bolt 132mm FE35 23C Tractor Cylinder Head Bolt (2 Required per tractor). Exclusive To Agriline.

£7.56 Inc VAT £6.30 Exc VAT

In stock

Qty

Part No.

A-855

Cylinder Head Stud 130mm FE35 23C Tractor Cylinder Head Stud, 5 Required per Tractor. Exclusive To Agriline.

£4.42 Inc VAT £3.68 Exc VAT

In stock

Qty

Part No.

A-852

Cylinder Head Stud Kit Cylinder Head Stud Kit, Suitable For 4 Cylinder Perkins A4.236 Engines. Kit Contains:- 12 Studs:- 56MM Long. 8 Studs:- 142MM Long. 2 Studs:- 106MM Long. 22 Nuts. 22 Spring Washers.

£49.99 Inc VAT £41.66 Exc VAT

In stock

Qty

Part No.

80077

Cylinder Head Stud Kit Includes: 8 x 3 5/8" x 7/16" UNF 11 x 4 1/4" x 7/16" UNF 4 x 4 1/8" x 7/16" UNF

£61.00 Inc VAT £50.83 Exc VAT

Out of stock

Qty

Part No.

80078

Cylinder Head Stud (Long) Cylinder Head Stud (Long) Overall Length: 195mm Thread: 7/16 UNC

£5.52 Inc VAT £4.60 Exc VAT

In stock

Qty

Part No.

80079

Cylinder Head Stud 125mm Long Engine Cylinder Head Stud (10 per Tractor) 7/16" N.C. & N.F. x 4 27/32" 80mm Only. Exclusive To Agriline.

£9.44 Inc VAT £7.87 Exc VAT

In stock

Qty

Part No.

A-856

Cylinder Head Bolt 125 mm FE35 23C Tractor Cylinder Head Bolt (9 required per tractor) Exclusive To Agriline!

£7.56 Inc VAT £6.30 Exc VAT

In stock

Qty

Part No.

A-850

Cylinder Head Stud (Pack of 9) 1/2" UNC, 9 Studs Per Pack. Grade 4F. Manufacturers recommended Torque procedure: 1. Tighten to 100Nm. 2. Tighten to 150Nm. 3. Wait 5 minutes, then re-check at 150Nm 4. Rotate bolt a further 60 Degrees

£23.99 Inc VAT £19.99 Exc VAT

In stock

Qty

Part No.

1464

Stepped Stud 148.5 mm Length 731366M1 6 Required.

£8.82 Inc VAT £7.35 Exc VAT

In stock

Qty

Part No.

7621

Stud 105.5 mm Length 731366M1 8 Required.

£7.44 Inc VAT £6.20 Exc VAT

In stock

Qty

Part No.

7622

Cylinder Head Bolt Cylinder Head Bolt Short Overall Length: 127mm Thread: 7/16 UNC

£5.52 Inc VAT £4.60 Exc VAT

In stock

Qty

Part No.

4734

Injector Stud AD3.152 Injector Stud 5/16 x 53mm

£1.51 Inc VAT £1.26 Exc VAT

In stock

Qty

Part No.

74151

Phaser 1004.40 Cylinder Head Bolt Kit Consists Of The Following Bolts: M12 X 1.2 Thread, 129mm Long x 2 M12 X 1.2 Thread, 108mm Long x 12 M12 X 1.2 Thread, 92mm Long x 8 Suitable for Builds: AA. AB, AC AD, AG, AH, AJ, AK Also Suitable For Pekins 4.236 - LD Builds

£80.40 Inc VAT £67.00 Exc VAT

In stock

Qty

Part No.

74596

Cylinder Head Bolt Kit Kit Contains: 1 x Long Bolt 15 x Short Bolt

£72.00 Inc VAT £60.00 Exc VAT

In stock

Qty

Part No.

75499
