Hydraulic Top Link Kit (Cat. 3) with Knuckle / Hook Ends Models 7010, 7020, 7200, 7210, 7220, 7320, 7400, 7410, 7420, 7425, 7465, 7475, 7480, 7485, 7490, 7495, 7505, 7510, 7515, 7520, 7525, 7600, 7610, 7620, 7700, 7710, 7720, 7800, 7810, 7820, 7920
Part No.
Product Details
80620A
Product Details
Supplied with 900mm Length Hoses with 1/2" Fittings & Release Chain.
Suitable for Tractors up to approx. 147 HP.
Bore Ø: 90mm.
Rod Ø: 45mm.
Stroke: 190mm.
Knuckle Hole: 32mm.
Knuckle Width: 51mm.
Ball I.D: 32.1mm.
Minimum Length: 610mm.
Maximum Length: 800mm.
Pull / Push Capacity: 8.59 / 11.45 Ton.
Suitable for Tractors up to approx. 147 HP.
Bore Ø: 90mm.
Rod Ø: 45mm.
Stroke: 190mm.
Knuckle Hole: 32mm.
Knuckle Width: 51mm.
Ball I.D: 32.1mm.
Minimum Length: 610mm.
Maximum Length: 800mm.
Pull / Push Capacity: 8.59 / 11.45 Ton.
