Case International 4200 Series 4210 Engine PARTS
We stock a wide range of high quality replacement tractor engine spare parts to suit Case International 4210 tractors. All parts come with an 18 months warranty. Our range includes; cylinder heads, gaskets, valves, engines, blocks, pistons, liners, piston rings, Seals, engine overhaul Kits, fuel pumps, oil pumps, crankshafts, engine bearings, oil filters, fuel filters, fuel pipes, manifolds, silencers and much more.
Cylinder Head Gasket
-
Head Gasket Set suitable for Case International - 1967014C1 3136799R99 Case Engines D206, D239, D246, D268, DT239£33.00 Inc VAT £27.50 Exc VATIn stockPart No.8516
Rocker Cover Gaskets
-
Rocker Cover Gasket suitable for Case International - 3138642R1 3138642R2 Rocker Cover Gasket£5.40 Inc VAT £4.50 Exc VATIn stockPart No.80093
Valves Engine
-
Inlet Valve 3055055R2 suitable for Case International - 3055055R2 Inlet Valve,Single Groove Collet9.90MM Stem OD145.9MM Overall Length43MM Head Diameter£7.76 Inc VAT £6.47 Exc VATIn stockPart No.80592 -
Exhaust Valve suitable for Case International - 3055056R2 Exhaust ValveDimensions- Overall Length: 146mm- Head Diameter: 41mm- Stem Diameter: 10mm- Angle: 45 Degrees£8.46 Inc VAT £7.05 Exc VATIn stockPart No.80593
Valve Guides
-
Valve Guide suitable for Case International - 129322A1 3055022R2 Valve Guide, requires reaming to match valve stem size16MM OD77.4MM Long£2.94 Inc VAT £2.45 Exc VATOut of stockPart No.7613
Valve Springs
-
Inlet/ Exhaust Valve Spring suitable for Case International - 3055060R1 3053060R1 Inlet/ Exhaust Valve Spring£4.14 Inc VAT £3.45 Exc VATIn stockPart No.80594
Valve Ancillaries
-
Valve Tappet suitable for Case International - Valve Tappet£9.48 Inc VAT £7.90 Exc VATIn stockPart No.80595
Engine Kits
-
Engine Overhaul Kit- D239 Engine suitable for Case International - Case Engine D239, 98.425 Bore x 128.50 Stroke Consists of; 4 x Piston, Pin & Clips 4 x Ring Set 4 x FInished Liner 4 x Liner Seal (Red Stripes) 4 x Liner Seal (Gold Stripes) 4 x Small End Bush (40 x 35.25 x 33.60mm) 1 x Head Gasket Set 1 x... Show More£330.00 Inc VAT £275.00 Exc VATOut of stockPart No.8550
Oil Pumps
-
Oil Pump suitable for Case International - 3136430R95 Case Engines D206, D239, D246, D268, DT268£201.00 Inc VAT £167.50 Exc VATIn stockPart No.8712
Oil Lines
-
Oil pressure Switch suitable for Case International - 3055238R92 3129031R91 3132673R2 Thread: 3/8" UNF.
Operating pressure: 20-50 PSI.
Max Pressure: 1450 PSI.
For guidance only, outside diameter of thread 9mm (+-0.5mm)
For 1/8 Fitting Use Ref 9063
£12.00 Inc VAT £10.00 Exc VATIn stockPart No.7058A
Piston Engine
-
Piston, Pin & Clips suitable for Case International - 194475A1 Piston Length: 107.13mm.
Chamber Depth: 22.15mm.
Pin Diameter: 36mm.£31.56 Inc VAT £26.30 Exc VATIn stockPart No.9579 -
Piston, Pin & Clips suitable for Case International - B3365 Al-Fin Ring Use Piston Ring Set 8505. Pin Diameter: 36mm.£40.80 Inc VAT £34.00 Exc VATIn stockPart No.8504
Piston Rings Engine
-
Piston Ring Set suitable for Case International - 3139594R91 Use With Piston 8504.
Has chamfered edges on No.1 Ring, as per original piston.£18.00 Inc VAT £15.00 Exc VATIn stockPart No.8505
Liners Engine Cyl
-
Liner suitable for Case International - 3144682R3 Liner FinishedDimensions- Bore Diameter: 100mm- Overall Height: 216mm- Outer Diameter: 111.50mm- Lip Diameter: 110.38mmShow More£28.80 Inc VAT £24.00 Exc VATIn stockPart No.9577
Liner Finished suitable for Case International - 3139592R4 Finished LinerDimensions- Bore Diameter: 98.425mm- Outer Diameter: 111.125mm- Overall Length: 216.13mm- Fla... Show More£22.80 Inc VAT £19.00 Exc VATIn stockPart No.8506Liner Shims & ORings
-
Liner Seal Gold Stripes suitable for Case International - 3228348R1 Case Engines; D155, D179, D206, D239, D246, D310 D358. 4.75mm Thick 109 ID mm£3.60 Inc VAT £3.00 Exc VATIn stockPart No.8508
Crankshafts
-
Crankshaft suitable for Case International - 3132982R94 3144626R91 3144626R92 CrankshaftD239 & D246.Mains: 3.1485"/3.1492"Conrods: 2.5185"/2.5192"Stroke: 5070"Lip SealHoles: 7+1&nb... Show More£510.00 Inc VAT £425.00 Exc VATIn stockPart No.8512
Conrod Bearings
-
Conrod Bearing Pair STD suitable for Case International - 3055351R91 Conrod Bearing Pair STD£5.99 Inc VAT £4.99 Exc VATIn stockPart No.1817 -
Conrod Bearing Pair STD suitable for Case International - 3144688R92 1 Pair. Lug On The Left. Standard Size 30mm£15.00 Inc VAT £12.50 Exc VATIn stockPart No.8829 -
Conrod Bearing Set + 0.010" suitable for Case International - 3056834R11 + 0.010" for 4 Cyl. Applications,£26.40 Inc VAT £22.00 Exc VATIn stockPart No.7088A -
Conrod Bearing Set STD suitable for Case International - 3055351R91 Standard Size. Suitable for 4 Cyl. Applications,£21.59 Inc VAT £17.99 Exc VATIn stockPart No.7088 -
Conrod Bearing Set + 0.020" - Case International 3056179R11 suitable for Case International - 3056179R11 + 0.020" for 4 Cyl Applications,£26.40 Inc VAT £22.00 Exc VATIn stockPart No.7088B
Main Bearings
-
£7.20 Inc VAT £6.00 Exc VATIn stockPart No.7076 -
Main Bearings Set STD suitable for Case International - 3055129R21 3055130R21 Main Bearings Set STD£40.80 Inc VAT £34.00 Exc VATIn stockPart No.80163 -
Currently unavailablePart No.80164 -
£5.88 Inc VAT £4.90 Exc VATIn stockPart No.7076A -
£5.88 Inc VAT £4.90 Exc VATIn stockPart No.7076B
Conrod Bushes
-
Small End Bush- 40 x 35.25 x 33.60mm suitable for Case International - 3132018R1 3132018R2 Case IH Engines; D155, D179, D206, D239, D246, D310, D358£4.50 Inc VAT £3.75 Exc VATIn stockPart No.8513
Gears Crank
-
Flywheel Ring Gear suitable for Case International - 60883H 126 Teeth.
O.D: 404mm.
£51.00 Inc VAT £42.50 Exc VATOut of stockPart No.80099
Crankshaft Gaskets
-
Rear Main Housing Gasket suitable for Case International - 3055215R2 Rear Main Housing Gasket£3.54 Inc VAT £2.95 Exc VATIn stockPart No.80094
Crankshaft Seals
-
Front Crank Seal suitable for Case International - 3228401R91 80 x 100 x 13mm Case Engines; D155, D179, D206, D239, D246, D310, D358, DT239, DT268, DT358, DT402£10.68 Inc VAT £8.90 Exc VATIn stockPart No.8518 -
Rear Crank Seal suitable for Case International - 3138701R91 130 x 110 x 13mm£10.50 Inc VAT £8.75 Exc VATIn stockPart No.8519 -
Front Crankshaft Seal Kit suitable for Case International - 3228133R93 Contains: 1 x O-Ring. 1 x Distance Ring. 1 xOil Seal. 3 x Dowel Pins.£47.99 Inc VAT £39.99 Exc VATIn stockPart No.4508
Fly Wheel
-
Flywheel -1808412C92 suitable for Case International - 1808412C92 For Clutch 300mm Diameter With 126 Teeth£426.34 Inc VAT £355.28 Exc VATIn stockPart No.72555 -
Fly Wheel Dowel suitable for Case International - 3/8 Diameter£1.44 Inc VAT £1.20 Exc VATIn stockPart No.92433 -
Flywheel Assembly 12"/126T suitable for Case International - 1808412C92 85118C91 Flywheel assembly 12"/126T.Currently unavailablePart No.76351
Bottom Gasket Sets
-
Bottom Gasket Set suitable for Case International - 1967011C1 3136813R99 Case Engines D206, D239, D246, D268, DT239.£35.40 Inc VAT £29.50 Exc VATOut of stockPart No.8517
Air Filters
-
Outer Air Filter suitable for Case International - 3125342R1 3125342R2 Air Filter - Outer OD: 6 3/32" / 154.8mm ID: 3/4" / 19.1mm & 3 15/32" / 88.1mm Length: 11 1/2" / 292.1mm£23.40 Inc VAT £19.50 Exc VATIn stockPart No.10115 -
Inner Air Filter suitable for Case International - 3125255R1 OD: 3 3/8" / 85.7mm.Flange: 4 5/32" / 105.6mm.ID: 11/16" / 17.5mm & 2 29/32" / 73.8mm.Length: 10 3/32 / 256.4mm.Currently unavailablePart No.10116 -
Fleetguard AF1861K Outer Air Filter suitable for Case International - 3125342R2 3125342R1 Outer Air Filter£43.96 Inc VAT £36.63 Exc VATOut of stockPart No.AF1861K -
Air Filter Kit - 3125342R1 suitable for Case International - 3125342R1 3125342R2 3125255R1Agriline Air Filter KitIncludes both Inner and Outer Air FilterInner Air Filter: 3125255R1Overall Length: 256mm.Filter Outer Diameter: 84mm.<... Show More£33.60 Inc VAT £28.00 Exc VATIn stockPart No.10563
Oil Filters
-
Oil Filter suitable for Case International - 3136046R91 3136046R93Spin On Oil Filter- Length: 136.9mm.- Diameter: 94.3mm- Thread: 1'' - 12 UNF£8.40 Inc VAT £7.00 Exc VATOut of stockPart No.10110 -
Fleetguard LF3532 Oil Filter suitable for Case International - 3136046R92 3136046R93 3136046R91 Overall height: 109mm, OD: 93mm, Thread size: 1 - 12 UNF-2B UNF-2B,£13.18 Inc VAT £10.98 Exc VATIn stockPart No.LF3532 -
Fleetguard LF3382 Oil Filter suitable for Case International - 398080R1 398080R2 Overall height: 175mm, OD: 93mm, Thread size: 1 - 12 UNF-2B UNF-2B,£16.92 Inc VAT £14.10 Exc VATIn stockPart No.LF3382
Fuel Filters
-
Dual Filter Assembly suitable for Case International - Dual Filter Assembly£30.00 Inc VAT £25.00 Exc VATIn stockPart No.7219 -
Fuel Filter - 1931128 suitable for Case International - 1931128 218100A1 3131428R1 Spin On Fuel FilterDimensionsOverall Length: 153.8mmDiameter: 79mmFor Fleetguard brand order FF5135£10.20 Inc VAT £8.50 Exc VATIn stockPart No.50347 -
£18.40 Inc VAT £15.33 Exc VATIn stockPart No.FF5171
Filter Kits
-
Filter Service Kit suitable for Case International - With Air Con.Contains:1 x Oil Filter.2 x Fuel Filter.1 x Outer Air Filter.1 x Inner Air Filter.£47.40 Inc VAT £39.50 Exc VATOut of stockPart No.FSK507
Fuel Lift Pumps
-
Fuel Primer Pump suitable for Case International - 1202938C92 1202938C93 Sucks In at Long Port£21.60 Inc VAT £18.00 Exc VATIn stockPart No.55014
Fuel Injectors
-
Injector Sleeve suitable for Case International - 3055344R1 Injector Sleeve£21.00 Inc VAT £17.50 Exc VATOut of stockPart No.80505
Fuel Injector Nozzle
-
£18.54 Inc VAT £15.45 Exc VATIn stockPart No.80156 -
Injector Nozzle suitable for Case International - 3218248R2 Injector Nozzle£18.32 Inc VAT £15.27 Exc VATIn stockPart No.1821
Fuel Tanks
-
Fuel Tank Cap suitable for Case International - 249517A1 255345A1Suitable For Tractors with XL cabsID: 40mm.
OD: 60mm.£34.80 Inc VAT £29.00 Exc VATOut of stockPart No.74658
Fuel Ancillaries
-
Lockable Fuel Cap suitable for Case International - 226384A1 UK Made. Case/IH. 3200 Series - From Serial Number JJE0925810.
£17.94 Inc VAT £14.95 Exc VATIn stockPart No.50443 -
Fuel Sender Unit suitable for Case International - 134122A1 Fuel Sender Unit£17.82 Inc VAT £14.85 Exc VATIn stockPart No.8141 -
Fuel Cap suitable for Case International - 226384A1 UK Made. Male Thread£12.28 Inc VAT £10.23 Exc VATIn stockPart No.50442 -
Fuel Tank Tap suitable for Case International - 528926r1 1/2" - 20 x 3/8" - 18 NPTFIn stockPart No.74304 -
Fuel Filter Head suitable for Case International - S400030 Bosch TypeInlet Thread: M14 x 1.5mmOutlet Thread: M14 x 1.5mm£16.80 Inc VAT £14.00 Exc VATIn stockPart No.75407
Stop Cables
-
Stop Cable suitable for Case International - 1333179C1 1965053C2 For Models with VE Injection pump 1370mm.
XL Cab tractors£21.00 Inc VAT £17.50 Exc VATIn stockPart No.4077
Hand Throttle Cables
-
Throttle Cable suitable for Case International - 3401585R2 3401585R3 Models With XL or LP Cab. Length: 1450mm.£15.00 Inc VAT £12.50 Exc VATIn stockPart No.1776
Fuel Filter Housings
-
Twin Fuel Filter Head - 3132491R1 suitable for Case International - 3144992R91 3218072R1 3136300R92 Suitable for spin on fuel filtersTo be used with Agriline Part No. 50347 Fuel FilterThread: M14 x 1.5mm£46.80 Inc VAT £39.00 Exc VATIn stockPart No.75592
Filler Caps Oil
-
Oil Filler Cap suitable for Case International - 3136337R91 Oil Filler Cap£28.80 Inc VAT £24.00 Exc VATIn stockPart No.74784
Exhaust Manifold
-
Exhaust Manifold suitable for Case International - 3136066R12 Exhaust Manifold£96.00 Inc VAT £80.00 Exc VATOut of stockPart No.8755
Gaskets Manifold
-
Exhaust Manifold Gasket suitable for Case International - 3132434R1 Exhaust Manifold Gasket£1.56 Inc VAT £1.30 Exc VATOut of stockPart No.8750
Exhaust Elbow
-
Exhaust Elbow suitable for Case International - 136174A3 Length: 318mm.£95.99 Inc VAT £79.99 Exc VATIn stockPart No.6603 -
Exhaust Elbow 182659A2 suitable for Case International - 182659A2 Genuine Part.
For Models With Lift Off Silencers & Tilting Bonnet.
Length: 218mm£78.00 Inc VAT £65.00 Exc VATIn stockPart No.6590 -
Exhaust Elbow suitable for Case International - 136174A3 Genuine Part.
Length: 318mm.£179.99 Inc VAT £149.99 Exc VATIn stockPart No.6589 -
Exhaust Elbow suitable for Case International - 182659A2 For Models With Lift Off Silencers & Tilting Bonnet Length: 218mmCurrently unavailablePart No.74174
Exhaust Clamp
-
£3.48 Inc VAT £2.90 Exc VATIn stockPart No.A-444
