Two-Way Shut Off Valve - 1/2" BSPP Female Thread
Part No.
Product Details
57030
Product Details
Two-Way Shut Off Valve - 1/2" BSPP Female Thread
This series of two-way high-pressure ball valves are designed to suit a wide range of applications. These valves should not be used as flow control valves and should therefore always be fully open or closed.
Thread: 3/8" BSPP
H: 52.2mm / 2.06"
H1: 17.0mm / 0.67"
H2: 8.7mm / 0.34"
L1: 35.0mm / 1.38"
H3: 40.0mm / 1.57"
L2: 4.8mm / 0.19"
D1: 6.5mm / 0.26"
L3: 37.5mm / 1.48"
L4: 83.0mm / 3.27"
APPLICATIONS
• Agricultural
• Construction
• Mobile hydraulics
• General hydraulic systems
• Machine Tools
• Test Equipment
FEATURES
• Floating ball design maximises sealing
• Full bore valves provide unrestricted flow path for negligible pressure drop
• Open to close in 1/4 turn
• Offset handle allows clearance for easy operation
SPECIFICATIONS
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Carbon steel body with trivalent plating
• Zinc alloy handle
• Forged steel option available
• Fitted with Nitrile & POM seals as standard
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure - 500 bar (Flow in Litres Per Minute) - 7250 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 2000 bar (Flow in Litres Per Minute) - 29000 PSI (Flow in Gallons Per Minute)
• Rated Flow - 45 bar (Flow in Litres Per Minute) – 12 PSI (Flow in Gallons Per Minute)
