Related Items(1)
Quick Release Coupling - Female - Body Size 1/4"
Part No.
Product Details
57001
Product Details
Quick Release Coupling - Female - Body Size 1/4" - Thread Size 1/4" BSPP
This series of couplings are designed with a poppet valve for quick connection and disconnection. They are interchangeable with the ISO A couplings in 1/2" size.
Body Size: 1/4”
Thread: 1/4" BSPP
L1: 55.5mm / 2.19"
D1: 27.6mm / 1.09"
A/F: 22.2mm / 0.87"
APPLICATIONS
• Agricultural
• Construction
• Mobile
• General hydraulics
FEATURES
• Poppet valves have balanced springs
• Locking ball system allows quick connection
• Bidirectional flow
SPECIFICATIONS
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Carbon steel with trivalent plating
• Fitted with NBR seals
• Conforms to ISO 5675.
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure (Coupled) - 375 bar (Flow in Litres Per Minute) - 5437 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 1600 bar (Flow in Litres Per Minute) - 23200 PSI (Flow in Gallons Per Minute)
• Rated Flow - 3 bar (Flow in Litres Per Minute) – 0.8 PSI (Flow in Gallons Per Minute)
