Double Blower Motor - SPAL 30001803
suitable for New Holland - 82002761 82004366 90070010 Models T4020, T4030, T4040, T4050, T5030, T5040, T5050, T5060, T5070, TL100, TL100A, TL70, TL70A, TL80, TL80A, TL90, TL90A, TN85A, TN95A
Part No.
Product Details
76473
Product Details
Overall Length: 317mm.
Overall Height: 112mm.
Overall Width: 125mm.
Mounting Base Length: 317mm.
Mounting Base Width: 86mm.
12v.
Double Blower Wheel.
360 CFM.
14.1A Current Draw.
3 Speeds. Small Resistor Supplied.
Wire Harness With AMP Connector Supplied.
Maximum Airflow (At Zero Static Pressure): 360FM (610m³/h).
Standard Features: Long Life.
Operating Voltage: 12v.
IP Rating: IP30.
SPAL Type / Description: 005-A45-02 L301 RPA3VCB.
CB: Wire Harness With AMP Connector.
RPA: Small Resistor.
3V: 3 Speeds.
Mounting Bolt/Screw: M4 Screw.
Mounting Torque: 3(+1/-0) Nm.
Certifications: UNI EN ISO 9001:2008, ISO TS 16949, ISO 14001.
Suitable For - New Holland models , T4020, T4030, T4040, T4050, T5030, T5040, T5050, T5060, T5070, TL100, TL100A, TL70, TL70A, TL80, TL80A, TL90, TL90A, TN85A, TN95A for OEM's 82002761, 82004366, 90070010
