Hydraulic Top Link Kit (Cat. 3) with Knuckle/ Hook Ends Models 6010, 6010SE, 6020, 6020SE, 6110, 6110L, 6120, 6120L, 6120S, 6200, 6205, 6210, 6210L, 6210SE, 6215, 6220, 6220L, 6225, 6300, 6310, 6310S, 6320, 6320L, 6320N, 6320SE, 6325, 6400, 6403, 6405, 6410, 6410L, 6415, 6420, 6420L, 6420S, 6420SE, 6425, 6500, 6500L, 6505, 6506, 6510, 6510L, 6515, 6520, 6520L, 6520SE, 6525, 6534, 6600, 6605, 6610, 6610SE, 6615, 6620, 6620SE, 6700, 6715, 6800, 6810, 6820, 6900, 6910, 6910S, 6920, 6920S, 6920SE, 7010, 7200, 7210, 7400, 7410, 7425, 7505, 7510, 7515, 7525, 7600, 7610, 7700, 7710, 7800, 7810

Part No.

Product Details

80641

Product Details

Supplied with 900mm Length Hoses with 1/2" Fittings & Release Chain.

Suitable for Tractors up to approx. 147 HP.
Bore : 90mm.
Rod : 40mm
Stroke: 200mm.
Knuckle Hole: 32mm.
Knuckle Width: 51mm.
Ball I.D: 32mm.
Minimum Length: 631mm.
Maximum Length: 831mm.
Pull / Push Capacity: 9.19 / 11.45 Ton.
