Double Blower Motor - SPAL 30000154 Models CS100, CS110, CS120, CS130, CS150, CS75, CS78, CS80, CS86, CS90, CS94, CVX120, CVX130, CVX150, CVX170, TVT135, TVT145, TVT155, TVT170, TVT190, TVT195, CVX1135, CVX1145, CVX1155, CVX1170, CVX1190, CVX1195
Part No.
Product Details
75393
Product Details
Overall Length: 351mm.
Overall Height: 140mm.
Overall Width: 168mm.
Mounting Base Length: 351mm.
Mounting Base Width: 136mm.
12v.
Double Blower Wheel.
537 CFM.
17.2A Current Draw.
3 Speeds. Aluminium Resistor Supplied.
Jumper Between Electric Motor And Resistor (No Wire Harness Included).
Maximum Airflow (At Zero Static Pressure): 537FM (910m³/h).
Standard Features: Long Life.
Operating Voltage: 12v.
IP Rating: IP30.
SPAL Type / Description: 006-A46-22 GR RA3VCV.
GR: Grid.
RA: Aluminium Resistor.
3V: 3 Speeds.
CV: Jumper Between Electric Motor And Resistor (Without Wire Harness).
Mounting Bolt/Screw: M4 Screw.
Mounting Torque: 3(+1/-0) Nm.
Certifications: UNI EN ISO 9001:2008, ISO TS 16949, ISO 14001.
