Double Blower Motor - SPAL 30000126 Models MXU100, MXU110, MXU115, MXU125, MXU130, MXU135, T6.120, T6.140, T6.150, T6.155, T6.160, T6.165, T6.175, T6010, T6020, T6030, T6040, T6050, T6060, T6070, T6080, T6090, T7.170, T7.185, T7.200, T7.210, T7.220, T7.235, T7.250, T7.260, T7.270, T7030, T7040, T7050, T7060, T7070, TS100A, TS110A, TS115A, TS120A, TS125A, TS130A, TS135A, T8.275, T8.300, T8.330, T8.360, T8.390, T8.420, T8.410, T8.320, T8.350, T8.380
Part No.
Product Details
74067
Product Details
For Case IH Magnum 235 with Serial No. up to Z8RZ06299.
For Case IH Maxxum 115, 125, 135, 140, 150, 180 with Iveco Engine.
Overall Length: 351mm.
Overall Height: 140mm.
Overall Width: 168mm.
Mounting Base Length: 351mm.
Mounting Base Width: 136mm.
12v.
Double Blower Wheel.
690 CFM.
31.1A Current Draw.
3 Speeds. Aluminium Resistor Supplied.
Jumper Between Electric Motor And Resistor (No Wire Harness Included).
Maximum Airflow (At Zero Static Pressure): 690CFM (1170m³/h).
Standard Features: Long Life.
Operating Voltage: 12v.
IP Rating: IP30.
SPAL Type / Description: 006-A39-22 RA3VCV.
RA: Aluminium Resistor.
3V: 3 Speeds.
CV: Jumper Between Electric Motor And Resistor (Without Wire Harness).
Mounting Bolt/Screw: M4 Screw.
Mounting Torque: 3(+1/-0) Nm.
Certifications: UNI EN ISO 9001:2008, ISO TS 16949, ISO 14001.
