BARE-Co AS30131 PTO Shaft Guard < 1500mm
Part No.
Product Details
91018
Product Details
BARE-Co AS30131 Lever Release PTO Shaft Guard - Large Diameter Shafts < 1500mm
To fit PTO shafts up to 1500mm long.
For larger diameter shafts.
Fits Shaft Closed Length: 1500mm.
Fits Shaft Max Working Length: 2500mm.
Fits Yoke Bearing Groove Diameters: 53mm- 83mm.
Universal Joint Bearing Cap Diameter: 30mm- 36mm.
This protective guard will fit the following series PTO Shafts;
Walterscheid - Series W2300S to W2600-25
Bondioli (BYPY) - Series 5-8 with Triangular Profile Tubing (World / Global Series)
Comer - Series T50 to T90
Weasler - Series 5 to 8
La Magdalena - Series 06 to 09
To determine the length of guard required, measure from yoke bearing groove to yoke bearing groove at either end of the PTO shaft.
To determine if you require a small or large diameter guard, measure the yoke bearing groove diameter. The smaller diameter guards fit shafts with a yoke bearing groove diameter 32mm to 53mm; larger diameter guards fit shafts with a yoke bearing groove diameter 53mm to 83mm.
All guards are supplied complete with collar, centre tubes, safety chains and a full set of bearings.
The BARE-Co Patented Lever Release PTO Guard can be unclipped from its bearing point at the yoke end which allows for guards to be pulled back to facilitate safe engagement of PTO shaft yokes and regular joint maintenance.
BARE-Co PTO Guards are claimed to be the most user friendly PTO guard in the world. Just two diameters cover virtually every brand of shaft sold in Europe.
Reusable. Easy Re-Greasing. Safe. UV Resistant. Hard Wearing.
Approvals: C.E. Approved, ISO 5674, ISO 12100, BS 12965.
