BARE-Co AS20091 PTO Shaft Guard < 1100mm
Part No.
Product Details
91030
Product Details
BARE-Co AS20091 Lever Release PTO Shaft Guard - Small Diameter Shafts < 1100mm
To fit PTO Shafts up to 1100mm long.
For smaller diameter shafts.
Fits Shaft Closed Length: 1100mm.
Fits Shaft Max Working Length: 1600mm.
Fits Yoke Bearing Groove Diameters: 32mm- 53mm.
Universal Joint Bearing Cap Diameter: Up to and equal to 27mm.
This protective guard will fit the following series PTO Shafts;
Walterscheid - Up to Series W2100
Bondioli (BYPY) - Up to Series 4 with Triangular Profile Tubing (Global Series)
Comer - Up to Series T40
Weasler - Up to Series AB4
La Magdalena - Up to Series 05
To determine the length of guard required, measure from yoke bearing groove to yoke bearing groove at either end of the PTO shaft.
To determine if you require a small or large diameter guard, measure the yoke bearing groove diameter. The smaller diameter guards fit shafts with a yoke bearing groove diameter 32mm to 53mm; larger diameter guards fit shafts with a yoke bearing groove diameter 53mm to 83mm.
All guards are supplied complete with collar, centre tubes, safety chains and a full set of bearings.
The BARE-Co Patented Lever Release PTO Guard can be unclipped from its bearing point at the yoke end which allows for guards to be pulled back to facilitate safe engagement of PTO shaft yokes and regular joint maintenance.
BARE-Co PTO Guards are claimed to be the most user friendly PTO guard in the world. Just two diameters cover virtually every brand of shaft sold in Europe.
Reusable. Easy Re-Greasing. Safe. UV Resistant. Hard Wearing.
Approvals: C.E. Approved, ISO 5674, ISO 12100, BS 12965.
