BARE-Co ASW7100G Wide Angle PTO Shaft Guard < 1500mm
Part No.
Product Details
91025
Product Details
BARE-Co ASW7100G Wide Angle Lever Release PTO Shaft Guard - Large Diameter Shafts < 1500mm
To fit PTO shafts up to 1500mm long.
For larger diameter shafts.
Fits Shaft Closed Length: 1500mm.
Fits Shaft Max Working Length: 2500mm.
Universal Joint Bearing Cap Diameter: 30mm- 36mm *Taken from non-wide angle end.
This protective guard will fit the following series PTO Shafts;
Walterscheid - W2480 & W2580 Series
La Magdalena - 35 & 36 Series
Weasler - WB6, WB8 & W2580 Series
Bare-Co - WB6, WB8 & W2580 Series
For use where bearing groove faces END of shaft *See photo.
To determine the length of guard required, measure from yoke bearing groove to yoke bearing groove.
All guards are supplied complete with collar, centre tubes, safety chains and a full set of bearings.
Much like the standard safety Bare-Co PTO guard, the Wide Angle Safety Guard allows the main cover to be opened after unlocking the quick release levers with a standard screwdriver. The entire guard can then be pulled back along the shaft for safe and efficient maintenance.
Reusable. Easy Re-Greasing. Safe. UV Resistant. Hard Wearing.
Approvals: C.E. Approved, ISO 5674, ISO 12100, BS 12965.
