Blower Motor - SPAL 30000556
suitable for John Deere tractor Models 3255
Part No.
Product Details
75295
Product Details
For John Deere 40 Series with Serial No. 500463 Onwards.
**Two blower motors are required in the John Deere Cab**
Product Info:
- Overall Length: 139mm.
- Overall Height: 146mm.
- Overall Width: 164mm.
- Mounting Base Length: 139mm.
- Mounting Base Width: 100mm.
- Blower Wheel.
- 19.6A Current Draw
- Includes Grid.
- Standard Connector Wire Harness Included.
- Maximum Airflow (At Zero Static Pressure): 319CFM (540m³/h).
- Standard Features: Low Noise, Long Life.
- Operating Voltage: 12v.
- IP Rating: IP30.
- SPAL Type / Description: 009-A70-74D 12v GR RPA.
- GR: Grid
- RPA: Small Resistor
- Airflow Direction: Clockwise.
- Mounting Bolt / Screw: M4 Screw.
- Mounting Torque: 3(+1/-0) Nm.
- Certifications: UNI EN ISO 9001:2008, ISO TS 16949, ISO 14001.
For mounting, use wide-head screw or washer to fasten the unit.
Suitable For - John Deere tractors models , 3255 for OEM's AL3914, AL39043
