Blower Motor - SPAL 30000556
suitable for John Deere tractor Models 2250, 2450, 2650, 2850, 3050, 3150, 3350, 3650
Part No.
Product Details
75295
Product Details
For John Deere 40 Series with Serial No. 500463 Onwards.
**Two blower motors are required in the John Deere Cab**
Product Info:
- Overall Length: 139mm.
- Overall Height: 146mm.
- Overall Width: 164mm.
- Mounting Base Length: 139mm.
- Mounting Base Width: 100mm.
- Blower Wheel.
- 19.6A Current Draw
- Includes Grid.
- Standard Connector Wire Harness Included.
- Maximum Airflow (At Zero Static Pressure): 319CFM (540m³/h).
- Standard Features: Low Noise, Long Life.
- Operating Voltage: 12v.
- IP Rating: IP30.
- SPAL Type / Description: 009-A70-74D 12v GR RPA.
- GR: Grid
- RPA: Small Resistor
- Airflow Direction: Clockwise.
- Mounting Bolt / Screw: M4 Screw.
- Mounting Torque: 3(+1/-0) Nm.
- Certifications: UNI EN ISO 9001:2008, ISO TS 16949, ISO 14001.
For mounting, use wide-head screw or washer to fasten the unit.
Suitable For - John Deere tractors models , 2250, 2450, 2650, 2850, 3050, 3150, 3350, 3650 for OEM's AL3914, AL39043
