Two-Way Shut Off Valve - 3/8" BSPP Female Thread
Part No.
Product Details
57029
Product Details
Two-Way High Pressure Ball Valve - 3/8" BSPP Female Thread
This series of two-way high-pressure ball valves are designed to suit a wide range of applications. These valves should not be used as flow control valves and should therefore always be fully open or closed.
Thread: 3/8" BSPP
H: 52.2mm / 2.06"
H1: 17.0mm / 0.67"
H2: 8.7mm / 0.34"
L1: 32.0mm / 1.26"
H3: 40.0mm / 1.57"
L2: 5.0mm / 0.20"
D1: 6.5mm / 0.26"
L3: 32.0mm / 1.26"
L4: 72.0mm / 2.83"
APPLICATIONS
• Agricultural
• Construction
• Mobile hydraulics
• General hydraulic systems
• Machine Tools
• Test Equipment
FEATURES
• Floating ball design maximises sealing
• Full bore valves provide unrestricted flow path for negligible pressure drop
• Open to close in 1/4 turn
• Offset handle allows clearance for easy operation
SPECIFICATIONS
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Carbon steel body with trivalent plating
• Zinc alloy handle
• Forged steel option available
• Fitted with Nitrile & POM seals as standard
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure - 500 bar (Flow in Litres Per Minute) - 7250 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 2000 bar (Flow in Litres Per Minute) - 29000 PSI (Flow in Gallons Per Minute)
• Rated Flow - 23 bar (Flow in Litres Per Minute) – 6.1 PSI (Flow in Gallons Per Minute)
